TYPE | PI-K | |
Resistance Input | 3 Wire Resistance | |
Lead Wire Resistance = 10Ω/Wire Max | ||
Field Programmable Zero From 5Ω to 20kΩ | ||
Field Programmable Span From 10Ω to 20kΩ | ||
Suitable for 2 Wire Connection (Offset Calibration Needed) | ||
Excitation | 0.8mA for Input < 2kΩ, 0.08mA for Input >= 2kΩ | |
Output | Voltage | Field Programmable From 500mVdc to ±12Vdc |
Maximum Output Drive = 10mA | ||
Current | Field Programmable From 1mAdc to ±20mAdc | |
Maximum Output Drive = 10Vdc (500Ω @ 20mA) | ||
Power | H | 85~264Vac/dc; 50/60Hz; 5VA |
M | 22~85Vac/dc; 50/60Hz; 5VA | |
L | 10~28Vac/dc; 50/60Hz; 5VA | |
Circuit Sensitivity | <±0.001%/V FSO Typical | |
Accurate to | <±0.1% FSO Typical | |
Linearity & Repeatability | <±0.1% FSO Typical | |
Ambient Drift | <±0.01%/C FSO Typical | |
Noise Immunity | 125dB CMRR Average (1600Vdc Limit) | |
MC Compliances | Emissions EN 55022-A, Immunity EN 50082-1, <1% Effect FSO Typical | |
Safety Compliance | EN 60950 | |
Mains Isolation | 250Vac | |
Isolation Test Voltages | Mains to Input/Output 3kVac 50Hz for 1min; Input to Output 1.6kVdc for 1min | |
Response Time | 200msec Typical (10 to 90% 50msec Typical) | |
Operating Temperature & Humidity | 0°C~60°C (Storage Temp -20°C~80°C) 5~85% RH Max, Non-Condensing | |
Dimensions and Mounting | L=80, W=50, H=120mm, Mounts on 35mm Symmetrical Mounting Rail |
PI-K – Resistance to DC Isolating Transmitter
Programmable Isolating 3 Wire Resistance Input to DC Current or DC Voltage Output Transmitter
PI-K Features
- Field programmable input and output ranges
- Bi-Polar output ranges
- Isolated input to output 1.6kV
- High accuracy 0.1%
- Universal AC/DC power supply
- Compact DIN Rail mount enclosure
- Available standard or special calibration
- Programmable input ranges from 0~10 ohms to 20k ohms
- Programmable output ranges from 0~500mV to ±12V, 0~1mA to ±20mA
Brand: INTECH
Usually in stock
Request a quoteScroll down for product range
Product Range
Code | Specifications | Price | Quantity | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
PI-K-X | Resistance Transmitter Standard Calibration: Input 0~1kΩ Output 4~20mA; High Voltage Power Supply | $670.00 | |||||||||
Other ranges available on request.
All prices are in NZ$, and GST exclusive and are subject to change without notice.Intech is our own brand of products, for all aftersales and technically support please contact us.
