| TYPE | PI-R | |
| RTD Input | Pt100 DIN (3 Wire Type) Standard | |
| Sensor Current = 0.8mA Typical | ||
| Lead Wire Resistance = 10Ω/Wire Max | ||
| Field Programmable Zero From -200°C~200°C | ||
| Field Programmable Span From 20°C~600°C | ||
| Suitable for 2 Wire Connection (Offset Calibration Needed) | ||
| Other Types of RTD Available: JIS Pt100, Pt250, Pt500, Pt1000, CU10, CU100, Ni100 or Specify | ||
| Output | Voltage | Field Programmable From 500mVdc to ±12Vdc |
| Maximum Output Drive = 10mA | ||
| Current | Field Programmable From 1mAdc to ±20mAdc | |
| Maximum Output Drive = 10Vdc (500Ω @ 20mA) | ||
| Power | H | 85~264Vac/dc; 50/60Hz; 5VA |
| M | 22~85Vac/dc; 50/60Hz; 5VA | |
| L | 10~28Vac/dc; 50/60Hz; 5VA | |
| Circuit Sensitivity | <±0.001%/V FSO Typical | |
| Accurate to | <±0.1% FSO Typical | |
| Linearity & Repeatability | <±0.1% FSO Typical | |
| Ambient Drift | <±0.01%/C FSO Typical | |
| Noise Immunity | 125dB CMRR Average (1600Vdc Limit) | |
| EMC Compliances | Emissions EN 55022-A, Immunity EN 50082-1, <1% Effect FSO Typical | |
| Safety Compliance | EN 60950 | |
| Mains Isolation | 250Vac | |
| Isolation Test Voltages | Mains to Input/Output 3kVac 50Hz for 1min; Input to Output 1.6kVdc for 1min | |
| Response Time | 200msec Typical (10 to 90% 50msec Typical) | |
| Operating Temperature & Humidity | 0°C~60°C (Storage Temp. -20°C~80°C) 5~85% RH Max, Non-Condensing | |
| Dimensions and Mounting | L=80, W=50, H=120mm. Mounts on 35mm Symmetrical Mounting Rail | |
PI-R – RTD Pt100 to DC Isolating Transmitter
Programmable, Isolating, 3 Wire RTD Input to DC Current or DC Voltage Output Transmitter
PI-R Features
- Field programmable input and output ranges
- Bi-Polar input and output ranges
- Isolated input to output 1.6kV
- Linear with temperature
- High Accuracy & linearity 0.1%
- Universal AC/DC power supply
- Compact DIN rail mount enclosure
- Available standard or special calibration
- Programmable ranges within -200~500°C
- Programmable output ranges from 0~500mV to ±12V, 0~1mA to ±20mA
Brand: INTECH
Usually in stock
Request a quoteScroll down for product range
Product Range
| Code | Specifications | Price | Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PI-R-X | RTD Transmitter Standard Calibration: Input 0ºC~100ºC; Output 4~20mA; Upscale Break; High Voltage Power Supply | $640.00 | |||||||||
Other ranges available on request.
All prices are in NZ$, and GST exclusive and are subject to change without notice.Intech is our own brand of products, for all aftersales and technically support please contact us.
